Cat 7 S/FTP 23AWG 4P/8P Communication Cables:

Basic Parameters

Cable Feature: This cable support all Class F applications like Ethernet, Fast Ethernet, Gigabit Ethernet, suitable for voice, data, CATV and sharing application installations up to 600MHz.

Bending Radius: 8×OD (during installation); 4×OD (fixed installed)

Temperature Range: -20℃ ~ +60℃

Stanards

EN 50173-1

EN 50288-4-1

ISO/IEC 11801

IEC 61156-5

IEC 60332-1 (for LSOH & FRLSOH Sheath)

IEC 60754-2 (for LSOH & FRLSOH Sheath)

IEC 61034 (for LSOH & FRLSOH Sheath)

IEC 60332-3-24 (for FRLSOH Sheath)

Construction

Conductors: Solid bare copper conductor.

Insulation: Foam skin PE.

Twinning: Two coloured insulated conductors twisted together to form a pair.

Individual Screen: Al/polyester tape.

Overall Screen: Tinned copper wire braid.

Outer Sheath: LSOH/FRLSOH.
