PHG Series Gasoline Engines Hydraulic Pump
China PHG Series Gasoline Engines Hydraulic Pump:
PHG Series Gasoline Engines Hydraulic Pump
This is a reasonable choice when there is no power supply and compressed air at work site.
Operating single-acting and double-acting hydraulic tools, the working pressure can reach 70 MPa external pressure regulating valve, and the pressure can be continuously adjusted between 7 and 70 MPa.
PHG series gasoline engines and hydraulic pumps have pre-installed one-way valves to prevent pressure loss from the forward position to the holding position.
Driven by a 4-stroke, 2.0kW HONDA engine, the pump has the lowest weight horsepower among all gasoline engines with forced air cooling function compared with ordinary gasoline engines.
PHG series pumps are equipped with tubular movable protector to prevent the pump from being damaged and easy to move.
| Model | Output Port | Engine Parameters | （MPa） Working Pressure | （L/min) Flow | Tank Volume (L) | Outer Size (LXWXH) (mm) | Reference Weight (KG) | ||||||
Displacement (cm3) | Speed (r/min) | High Pressure | Low Pressure | High Pressure | Low Pressure | ||||||||
| PHG120 | M16X1.5 | 163 | 3000 | 70 | — | 1.1 | — | 8 | 540×430×500 | 54 | |||
| PHG220 | M16X1.5 | 163 | 3000 | 70 | 6 | 1.1 | 6 | 8 | 540×430×500 | 54 | |||
