YWC-15ppm Bilge oily water separator with 1.5m3 per hour
Description:
This device 15ppm Bilge Water Separator is a kind of environmental protection product designed based on International Marinetime Organization IMO MEPC.107(49) standard, the oil content in effluent water ≤15ppm. This separator is the high tech newest product which can effectively dispose all kinds of fluids in bilge water including fuel oil, high-density residual oil and emulsion mixture combine with black ferric oxide and surfactant.
Technical data:
| YWC 1.5m3/h Oily Water Separator | |
| Rating Capacity | 1.5m3/h |
| Power of Pump | 0.37kw |
| Electric Heater Power | Option |
| 15ppm Bilge Alarm | Included |
| Base(Channel Steel) |
#6 1100x1130mm |
| Height | 1650mm |
| Dry/Wet Weight | 1060/1810kg |
| Applicable Ship Vessel |
10-30KDWT |
| Certificate | CCS GL |
| Optional Electric System |
AC 380V/50Hz/3 phase AC 415V/50Hz/3 phase AC 440V/60Hz/3 phase AC 480V/60HZ/3 phase |
