PROFIBUS 1 Pair 0.35mm2 Communication Cables

Category: IEC60092 Standard Offshore & Marine Cables
Certificate: ABS, LR, BV, DNVGL, NK, KR, IRS, RMRS, CCS
FOB Price: Get Latest Price Now
Warranty: 12 Months unless specified otherwise
Place of Origin: China
Request a Quote Print Page Dowdload Page

We can supply according to your requirement.

PROFIBUS 1 Pair 0.35mm2 Communication Cables

Basic Parameters

Cable Feature: These profibus cables are dedicated for fixed installation on board of ship, used as connection cables for digital signals up to 12MBd.

Bending Radius: 10×OD

Temperature Range: -35℃ ~ +80℃

Stanards

DIN VDE 0472 part 805

IEC 60332-1&2

IEC 60754-1/2

IEC 61034

Construction

Conductors: Stranded bare copper.

Insulation: Foam polyethylene (cellular HDPE).

Overall Screen1: Aluminium/polyester tape.

Overall Screen2: Tinned copper braid.

Inner Sheath: Halogen-free polymer HM4.

Outer Sheath: LSOH (SHF1).
