MRE-2X(St)HCH Overall Screened & Armoured Flame Retardant Instrumentation & Control Cables

MRE-2X(St)HCH Overall Screened & Armoured Flame Retardant Instrumentation & Control Cables

Basic Parameters

Cable Feature: flame retardant, low smoke & halogen free, suitable for installations on passenger ships, as on other commercial vessels.

Bending Radius: 6×OD
Temperature Range: -30℃ ~ +80℃

Standards

IEC 60092-350/351/376/359, IEC 60332-1, IEC 60332-3-22, IEC 60754-1/2, IEC 61034.

Construction

Conductors: Class 2 stranded copper conductor.

Insulation: XLPE.

Cabling Element: Pair/Triple.

Overall Screen: Al/polyester tape.

Inner Sheath: LSOH (SHF1).

Armour: Copper wire braid.

Outer Sheath: LSOH (SHF1). SHF2 can be offered upon request.
