Half Scissor Grab Bucket
Category:
Grab Bucket
Certificate:
ABS,LR,BV,DNVGL,NK,KR,IRS,RMRS,CCS
FOB Price:
Get Latest Price Now
Warranty:
12 Months unless specified otherwise
Place of Origin:
China
Request a Quote Print this page
We can supply according to your requirement.
Half Scissor Grab Bucket:
1.Half Scissor Grab Bucket

Half scissor grab is absorbed the advantages of long poles grab and scissor grab. Combined with the both of advantages, this grab bucket is composed of forearm, moving jackstay, static jackstay and gnathostegite, the central of forearm hinge joint gnathostegite, the other side equipped the down pulley, when working, lifting the down pulley, it will close gnathostegite, capture the materials, grasping force strong, opening easily, it is suitable for single rope and double rope grab bucket, load and unload the loose materials such as sand, coal, steel slag etc.

2.Half Scissor Grab Bucket
Model Volume m3 Grab selfweight t Rated lifting weight t Rate t/m3 Pulley rate
BJZ03-1 1.5 1.6 3 0.8-1.2 3
BJZ03-2 1 1.5 3 1.2-1.8 3
BJZ05-1 2 2.3 5 0.8-1.2 4
BJZ05-2 1.5 2.6 5 1.6-2.0 4
BJZ05-3 1 2.5 5 2.0-2.5 4
BJZ8-1 3.5 3.2 8 0.8-1.2 3
BJZ10-1 5 1.4 10 0.8-1.2 3
BJZ10-2 3.3 4.5 10 1.2-2.0 4
BJZ10-3 2.5 4.3 10 2.0-2.5 4
