Diesel slop water pump
Diesel slop water pump Technical parameter:
|
Set
|
Model
|
80KB-3WD
|
100KB-4WD
|
|
Name
|
Slope pump
|
|
Inlet/Outlet diameter
|
80mm(3")
|
100mm(4")
|
|
Cont. Capacity(m3/h)
|
45
|
80
|
|
Cont. Head lift(m)
|
25
|
25
|
|
Max.Suction head(m)
|
8
|
8
|
|
Engine
|
Engine model
|
178F
|
186F
|
|
Engine type
|
Single
cylinder,4-stroke,air cooled diesel engine
|
|
Displacement(CC)
|
296
|
418
|
|
Max.output power(HP)
|
7
|
10
|
|
Rated spee(RPM)
|
3600
|
3600
|
|
Fuel consumption ratio(g/kw.h)
|
<283
|
<280
|
|
starting method
|
Recoil start
|
|
Fuel tank capacity(L)
|
3.3
|
5.5
|
|
Options
|
Electric starter
|
Available
|
Available
|
|
Oil annunciator
|
Available
|
Available
|
|
Pack
|
Packing size(mm)
|
600x470x450
|
670x500x615
|
|
Net weight(Kgs)
|
61
|
66
|
|
Gross weight(Kgs)
|
63
|
70
|
|
20FT Qty
|
190
|
112
|
