CVF-30/30 Marine air compressor
Category:
Marine Medium Pressure Air-cooled Series Air Compressor
Certificate:
ABS,LR,BV,DNVGL,NK,KR,IRS,RMRS,CCS
FOB Price:
Get Latest Price Now
Warranty:
12 Months unless specified otherwise
Place of Origin:
China
Request a Quote Print this page
We can supply according to your requirement.
CVF-30/30 Marine air compressor:
Models: CVF-30/30 Marine air compressor

Type: V type, air cooled, two stage compression piston

Displacement: 30.0 m3 / h

The rated pressure: 3.0 MPa

Product features

1.With highly efficient, low noise, smooth operation.

2.Apply to ship host and all kinds of Marine diesel engine start, can also be used to start or braking of hydro power equipment, blow molding and rubber products, pressure vessel inspection, hyperbaric oxygen chamber, etc. It can also be for traffic construction and other industries to provide medium voltage source.

3.According to the needs of users of products can provide the following functions:two main for the functions of each control, temperature control, inlet pressure controller, exhaust outlet high pressure hose.

Main Technical Parameter

Model Displacement Specified Pressure Rotating Speed Motor Power Dimension(L×W×H) Weight
m3/h m3/ min MPa r/min kW HP mm kg
CZ-5/30FZK 5 0.08 3.0 520 2.2 3 970×480×750 170
CZ-10/30FZK 10 0.17 500 3 4 970×480×750 175
CZ-20/30FZK 20 0.34 1000 5.5 7.5 970×480×750 200
2ZF-0.34/30-B 20.4 600 940×500×850 210
2ZF-0.34/30-B (Vertical unit) 586×520×1020 185
CVF-30/30 30 0.5 500 7.5 10 1100×650×580 275
CVF-40/30 40 0.67 640 11 15 1100×650×580 300
CWF-60/30 60 1 650 15 20 1310×714×810 366
CZC-10/30F( Emergency air compressor) 10 0.17 500 KM178F Diesel engine 970×400×700 140
Diesel-engine Model KM178F Starting method: hand drawn centrifugal clutch
2ZFC-0.34/30-B(Emergency air compressor) 20.4 0.34 600 KM186F Diesel engine 1000×500×780 170
Diesel-engine Model KM186F Starting method: hand drawn centrifugal clutch
