CAN BUS CABLES

Category: IEC60092 Standard Offshore & Marine Cables
Certificate: ABS, LR, BV, DNVGL, NK, KR, IRS, RMRS, CCS
FOB Price: Get Latest Price Now
Warranty: 12 Months unless specified otherwise
Place of Origin: China
Request a Quote Print Page Dowdload Page

We can supply according to your requirement.

CAN BUS CABLES

Basic Parameters

Cable Feature: These cables are used to the shipbuilding industry.

Bending Radius: 10×OD

Temperature Range: -35℃ ~ +80℃

Stanards

IEC 60092- 350/351/352/353/359/370/376

IEC 60332-1-2

IEC 60332-3-22

IEC 60754-1/2

IEC 61034

Construction

Conductors: Stranded tinned copper 21AWG.

Insulation: Foam skin PP.

Inner Sheath: Thermoplastic copolymer (FRNC).

Overall Screen1: Aluminium/polyester tape.

Overall Screen2: Tinned copper braid.

Outer Sheath: LSOH (SHF1).
