A2.0-3 Marine Air receiver
Description:
A type : A vertical or inclination.
Marine Low-pressure air receiver is mainly used to store compressed air, and supply start up or air whistle for main engine and auxiliary engine.
A- type is made up of bottle valve and steel body. Body has handhole (or manhole) foe easy wash and examination, and bottle valve set up inlet/outlet valve, safety valve , pressure gauge and pressure gauge valve, drain valve etc.
Technical Data:
| Main Data | |
| Design Pressure | 3.3MPa |
| Working Pressure | 3.0MPa |
| Design Temperature | 100℃ |
| Volume | 2.0m3 |
| Hydraulic Test Pressure | 4.95MPa |
| Gad Tight Test Pressure | 3.0MPa |
