ZYFM3.0m3 Bilge oily water separator industrial waste water separator
China ZYFM3.0m3 Bilge oily water separator industrial waste water separator:
Description:
ZYFM series of bilge water separator is a new type of vacuum micro filter type oil-water separation devices, it is widely applicable to the bilge oily water and ports, docks, factories and treatment of oily wastewater, in full compliance with international seaweed organization IMO - MEPC107 (49), and can satisfy the rules of our government oily sewage discharge standard is less than 15 mg/l. Products have obtained certificate of China classification society type before and IMO approval notification.
| Model Number | ZYFM-3.0 |
| Treatment capability (m3 per hour) | 3 |
| Discharging standard | Equal or less than 15ppm |
| Design pressure | 0.2 Mpa |
| Types of pump | Single screw pump / plunger pump |
| Suction lift(m) | Equal or less than 6 |
| Power of motor(kw) | 2.2 |
| Electric heating power (KW) | 2 |
| Power supply | 220V 50HZ,380V 50HZ, 415V 50HZ,440V 60HZ |
| Gathering room heating method and power | Electric heating |
| 2kw | |
| Oil drainage mode | Automatic and manual |
| Dimension(LXWXH) | 2250X1380X2250 |
| Weight(kg) | 1600 |
