YB0 Series Marine Shackle Wire Rope Block
China YB0 Series Marine Shackle Wire Rope Block:
| Type |
Wheel Dia (mm) |
SWL (t) |
Size (mm) |
Weight (kg) |
Rope Dia (mm) |
|||
| A | B | C | D | |||||
| YBO75x1 | 75 | 0.5 | 230 | 85 | 26 | 12 | 1.5 | 8 |
| YBO100 x1 | 100 | 1 | 285 | 121 | 34 | 16 | 2.4 | 8 |
| YBO125 x1 | 125 | 1.5 | 346 | 145 | 38 | 18 | 4.2 | 9 |
| YBO150 x1 | 150 | 2 | 4199 | 180 | 41 | 22 | 6.4 | 12 |
| YBO200 x1 | 200 | 4 | 517 | 225 | 46 | 28 | 12.5 | 16 |
| YBO250 x1 | 250 | 5 | 655 | 275 | 60 | 28 | 16 | 22 |
| YBO75x2 | 75 | 0.5 | 230 | 85 | 50 | 12 | 2.1 | 8 |
| YBO100 x2 | 100 | 1 | 285 | 121 | 61 | 16 | 3 | 8 |
| YBO125 x2 | 125 | 1.5 | 355 | 145 | 73 | 18 | 5.9 | 9 |
| YBO150 x2 | 150 | 2 | 365 | 180 | 83 | 22 | 9 | 12 |
| YBO200 x2 | 200 | 4 | 517 | 225 | 93 | 28 | 17.5 | 16 |
| YBO250 x2 | 250 | 5 | 600 | 275 | 115 | 28 | 28.6 | 22 |
