YB Series Marine Shackle Wire Rope Block
China YB Series Marine Shackle Wire Rope Block:
| Type |
Wheel Dia (mm) |
SWL (t) |
Size (mm) |
Weight (kg) |
Rope Dia (mm) |
|||
| A | B | C | D | |||||
| YB75x1 | 75 | 0.5 | 178 | 85 | 26 | 12 | 1.1 | 8 |
| YB100 x1 | 100 | 1 | 235 | 121 | 34 | 16 | 1.8 | 8 |
| YB125 x1 | 125 | 1.5 | 305 | 145 | 38 | 18 | 3.5 | 9 |
| YB150 x1 | 150 | 2 | 350 | 180 | 41 | 22 | 5.1 | 12 |
| YB200 x1 | 200 | 4 | 425 | 225 | 46 | 28 | 11.5 | 16 |
| YB250 x1 | 250 | 5 | 495 | 275 | 60 | 28 | 17 | 22 |
| YB75x2 | 75 | 0.5 | 178 | 85 | 50 | 12 | 1.8 | 8 |
| YB100 x2 | 100 | 1 | 235 | 121 | 61 | 16 | 2.8 | 8 |
| YB125 x2 | 125 | 1.5 | 305 | 145 | 73 | 18 | 5.5 | 9 |
| YB150 x2 | 150 | 2 | 350 | 180 | 83 | 22 | 8.5 | 12 |
| YB200 x2 | 200 | 4 | 425 | 225 | 93 | 28 | 16.5 | 16 |
| YB250 x2 | 250 | 5 | 495 | 275 | 115 | 28 | 25.5 | 22 |
