HC Series Single Wheel Marine Wire Block
China HC Series Single Wheel Marine Wire Block:
| Type | SWL(KN/T) | TL(Kn/T) |
Rope Dia （mm） |
A（mm） | B | C | D | |||
| L Type | N Type | Y Type | Q Type | |||||||
| 6-HC 2x1 | 20(2) | 80(8) | 43021 | 429 | 384 | 274 | 401 | 156 | 132 | 100 |
| 8-HC 3x1 | 30(3) | 120(12) | 16-20 | 568 | 482 | 482 | 501 | 196 | 164 | 124 |
| 10-HC 3x1 | 30(3) | 120(12) | 16-20 | 606 | 551 | 551 | 570 | 260 | 224 | 124 |
| 12-HC 5x1 | 50(5) | 200(20) | 20-22 | 685 | 643 | 643 | 658 | 300 | 260 | 135 |
| 14-HC 5x1 | 50(5) | 200(20) | 20-24 | 796 | 717 | 737 | 750 | 340 | 300 | 151 |
| 16-HC 10x1 | 100(10) | 400(40) | 24-26 | 945 | 881 | 881 | 897 | 406 | 356 | 190 |
| 17-HC 16x1 | 160(16) | 640(64) | 26-28 | 1018 | 948 | 948 | 968 | 430 | 378 | 192 |
| 18-HC 20x1 | 200(20) | 800(80) | 26-28 | 1095 | 1035 | 1035 | 1055 | 460 | 410 | 210 |
| 8-HC 5x2 | 50(5) | 100(10) | 16-20 | 458 | 498 | 498 | 517 | 194 | 164 | 166 |
| 10-HC 8x2 | 80(8) | 160(16) | 16-20 | 648 | 600 | 600 | 615 | 260 | 224 | 180 |
| 12-HC 10x2 | 100(10) | 200(20) | 20-22 | 130 | 680 | 680 | 688 | 300 | 260 | 205 |
| 14-HC 16x2 | 160(16) | 320(32) | 20-24 | 840 | 773 | 773 | 790 | 340 | 295 | 250 |
| 16-HC 20x2 | 200(20) | 400(40) | 24-26 | 1035 | 945 | 945 | 913 | 406 | 356 | 271 |
| 17-HC 25x2 | 250(25) | 500(50) | 26-28 | 1074 | 1010 | 1010 | 1035 | 460 | 378 | 308 |
| 18-HC 32x2 | 320(32) | 640(64) | 26-28 | 1174 | 1090 | 1090 | 1120 | 460 | 410 | 308 |
