WKODM-II Bilge Alarm 15PPM Oily Water
Main technical indicators:
Measurement range: 0 ~ 30ppm (50ppm);
Accuracy: + 5ppm. meets IMO MEPC.107 (49) requirements;
The alarm points can be adjusted between 1 and 2:0 to 15ppm (the factory is set to 15ppm).
Alarm point 1 (prompt alarm): action lag time between 0 to 30 seconds adjustable (factory set to 5 seconds), red LED indication;
Alarm point 2 (control function): action lag time between 0-255 seconds adjustable (factory set to 15 seconds), red LED indication;
The form of alarm output: passive relay contact output, load capacity 3A/250VAC or 3A/30VDC;
Inlet pressure: 0.01 ~ 1MPa;
Power supply: 100V-240V AC50-60Hz;
Ambient temperature and humidity: temperature: 0 C ~ 55 C
Relative humidity: no condensation on the surface of <95%
Supply CCS Certificate
