TG28 Search Light
Category:
75 KW Bow Thruster
Certificate:
ABS,LR,BV,DNVGL,NK,KR,IRS,RMRS,CCS
FOB Price:
Get Latest Price Now
Warranty:
12 Months unless specified otherwise
Place of Origin:
China
Request a Quote Print this page
We can supply according to your requirement.
TG28 Search Light:
The scope of application

This product is designed to use for illumination as search lighting at all kinds of ship, wharf, station, square, building site etc.

Products feature

1. Easy to install and replace the bulbs.

2. High lighting intensity and long illuminate distance.

3. The body of light is made of steel and stainless steel two type of material which surface be coated by ship special use powder with the feature of excellent corrosion and shock resistance.

4. High-pure reflector with imported light sources and can be used in temperature -20°above.

5. Matched joystick which can control to rotate the body of light 350 degree in horizontal and 30 degree in pitch by hand in cabin of ship.

6. The cable outside diameter is Φ10~Φ14mm.

Adopt standard and product certification

1. Conform to RULES FOR CLASSIFICATION OF SEA-GOING STEEL SHIPS.

2. Conform to GB7000.7 of SAFETY REQUIREMENTS FOR FLOOD LIGHT.

3. Conform to GD01 of GUIDELINES FOR TYPE APPROVAL TEST OF ELECTRIC AND ELECTRONIC PRODUCTS.

4. Approved by China Classification Society (CCS).

Installation

TG28 Search Light Specification

Type TG28
Power(W) 2000
Voltage(V) 220V/50HZ,220V/60HZ
Lamp Holder GY16
Llluminant Tungsten Halogen Lamp
Luminous Flux(Lm) 53000
Protection Class IP56
Weight( Kg) 35
