CZ-20/30FZK Marine air compressor
Category:
Marine Medium Pressure Air-cooled Series Air Compressor
Certificate:
ABS,LR,BV,DNVGL,NK,KR,IRS,RMRS,CCS
FOB Price:
Get Latest Price Now
Warranty:
12 Months unless specified otherwise
Place of Origin:
China
Request a Quote Print this page
We can supply according to your requirement.
CZ-20/30FZK Marine air compressor:
Model: CZ-20/30FZK Marine air compressor

Type: single row, air-cooled, two step piston type

Exhaust volume: 20.0 m3/h

Rated pressure: 3 MPa

It has the advantages of simple structure, high efficiency, light weight, small volume, low noise, stable operation; suitable for marine engine and various medium-sized diesel engine starting purposes, can also be used for hydro power station braking, various types of valves, instruments, pressure test and other fields as a source of pressure strength. Products according to user needs can provide the following functions: two machine main ready for mutual control function, temperature control function, import pressure controller, exhaust outlet high-pressure hose.

Product features

1.The type of single row, double row, V type, W type, two stage compression piston.

2.With the high efficiency, light weight, small volume, low noise, stable operation

3.The product has a manual / automatic stopping, starting and unloading relief function.

Main Technical Parameter

Model Displacement Specified Rotating Motor Power Dimension(L×W×H) Weight
Pressure Speed
m3/h m3/ min MPa r/min kW HP mm kg
CZ-20/30FZK 20 0.34 3 1000 5.5 7.5 970×480×750 200
