CS Series Marine Hand pump
Category:
Marine Hand pump
Certificate:
ABS,LR,BV,DNVGL,NK,KR,IRS,RMRS,CCS
FOB Price:
Get Latest Price Now
Warranty:
12 Months unless specified otherwise
Place of Origin:
China
Request a Quote Print this page
We can supply according to your requirement.
CS Series Marine Hand pump:
CS Series Marine Hand pump

Y type in the CS series pumps are used to draw oils or freshwater.H type in the CS series pumps are used to draw seawater.

Technical parameter:

type flow rate Head cylinder piston Reciprocating pump weight
diameter stroke frequency
Q(m3/h) m mm mm 1/min kg
cs-20 1.2 20-25 65 68 50 5.8
cs-20Y 1.2 25 65 68 50 5.8
cs-25Y 1.92 25 75 80 50 7.5
cs-32 2.4 20-25 88 90 50 11
cs-32Y 2.88 25 88 90 50 11
cs-40Y 3.9 25 95 96 50 12
