CLZ Marine Vertical self priming centrifugal pump:
CLZ Marine Vertical Self-Priming Centrifugal pump
CLZ Series marine pumps are used at cabin bottom to cool water and fight fire. It is able to carry sea water under 70 degrees.Fresh water and other nonerroding liquid.
Technical parameter:
| 380V 50Hz 3ph | ||||||||
| Model | Flow rate | Head | Speed | Npshr | Suction head | Shaft power | Motor power | Efficiency |
| m3/h | m | rpm | m | m | kw | kw | % | |
| 40CLZ-2 | 5 | 60 | 2900 | 3.5 | 6.5 | 3.93 | 5.5 | 19 |
| 50CLZ-3 | 12.5 | 50 | 2900 | 3.2 | 6.8 | 3.27 | 5.5 | 52 |
| 50CLZ-4.5 | 12.5 | 32 | 2900 | 3.2 | 6.8 | 2.53 | 4 | 43 |
| 50CLZ-4.5A | 10 | 28 | 2900 | 3.2 | 6.8 | 1.8 | 3 | 43 |
| 50CLZ-6 | 20 | 32 | 2900 | 3.2 | 6.8 | 3.23 | 4 | 54 |
| 50CLZ-6A | 17 | 28 | 2900 | 3.2 | 6.8 | 2.49 | 4 | 52 |
| 50CLZ-4 | 20 | 50 | 2900 | 3.2 | 6.8 | 5.45 | 7.5 | 50 |
| 50CLZ-4A | 17 | 46 | 2900 | 3.2 | 6.8 | 4.44 | 7.5 | 48 |
| 50CLZ-9 | 27 | 14.5 | 2900 | 3.2 | 6.8 | 2.54 | 3 | 42 |
| 65CLZ-5 | 25 | 45 | 2900 | 3.2 | 6.8 | 6.38 | 7.5 | 48 |
| 65CLZ-4.5 | 25 | 60 | 2900 | 3.2 | 6.8 | 8.33 | 11 | 49 |
| 65CLZ-3 | 25 | 80 | 2900 | 3.2 | 6.8 | 11.1 | 15 | 49 |
| 65CLZ-9 | 25 | 20 | 2900 | 3.2 | 6.8 | 3.24 | 4 | 42 |
| 65CLZ-6 | 25 | 32 | 2900 | 3.2 | 6.8 | 4.19 | 5.5 | 52 |
| 65CLZ-6A | 21 | 28 | 2900 | 3.2 | 6.8 | 3.14 | 4 | 51 |
| 65CLZ-8 | 35 | 32 | 2900 | 3.2 | 6.8 | 5.55 | 7.5 | 55 |
| 65CLZ-8A | 32 | 28 | 2900 | 3.2 | 6.8 | 4.52 | 5.5 | 54 |
| 65CLZ-5.5 | 35 | 50 | 2900 | 3.2 | 6.8 | 9.53 | 15 | 50 |
| 65CLZ-5.5A | 30 | 48 | 2900 | 3.2 | 6.8 | 8.17 | 11 | 48 |
| 65CLZ-4 | 35 | 70 | 2900 | 3.2 | 6.8 | 13.9 | 22 | 48 |
| 65CLZ-4A | 32 | 65 | 2900 | 3.2 | 6.8 | 12.1 | 15 | 47 |
| 80CLZ-13 | 45 | 21 | 2900 | 3.5 | 6.5 | 5.14 | 7.5 | 50 |
| 80CLZ-11 | 50 | 25 | 2900 | 3.5 | 6.5 | 7.09 | 7.5 | 48 |
| 80CLZ-7.5 | 60 | 50 | 2900 | 3.5 | 6.5 | 17.7 | 22 | 46 |
| 80CLZ-5 | 60 | 80 | 2900 | 3.5 | 6.5 | 22.5 | 30 | 58 |
| 80CLZ-9 | 50 | 32 | 2900 | 3.5 | 6.5 | 7.03 | 11 | 62 |
| 80CLZ-9A | 45 | 28 | 2900 | 3.5 | 6.5 | 5.6 | 7.5 | 61 |
| 80CLZ-9B | 54 | 21 | 2900 | 3.5 | 6.5 | 5.1 | 7.5 | 60 |
| 80CLZ-6 | 50 | 50 | 2900 | 3.5 | 6.5 | 11.7 | 15 | 58 |
| 80CLZ-6A | 45 | 48 | 2900 | 3.5 | 6.5 | 10.3 | 15 | 57 |
| 80CLZ-4 | 50 | 80 | 2900 | 3.5 | 6.5 | 21.8 | 30 | 50 |
| 80CLZ-4A | 50 | 70 | 2900 | 3.5 | 6.5 | 19.5 | 22 | 49 |
| 80CLZ-4B | 45 | 62 | 2900 | 3.5 | 6.5 | 16.2 | 18.5 | 47 |
| 80CLZ-3 | 50 | 120 | 2900 | 3.5 | 6.5 | 35.5 | 45 | 46 |
| 80CLZ-3A | 45 | 110 | 2900 | 3.5 | 6.5 | 29.3 | 37 | 46 |
| Model | Flow rate | Head | Speed | Npshr | Suction head | Shaft power | Motor power | Efficiency |
| m3/h | m | rpm | m | m | kw | kw | % | |
| 100CLZ-17 | 80 | 20 | 2900 | 4 | 6 | 7.26 | 11 | 60 |
| 100CLZ-12 | 80 | 32 | 2900 | 4 | 6 | 11.6 | 15 | 60 |
| 100CLZ-12A | 72 | 20 | 2900 | 4 | 6 | 9.3 | 15 | 59 |
| 100CLZ-8 | 80 | 50 | 2900 | 4 | 6 | 18.8 | 22 | 58 |
| 100CLZ-8A | 72 | 46 | 2900 | 4 | 6 | 15.8 | 18.5 | 57 |
| 100CLZ-6 | 80 | 80 | 2900 | 4 | 6 | 34.2 | 37 | 51 |
| 100CLZ-6A | 72 | 75 | 2900 | 4.5 | 5.5 | 29.4 | 37 | 50 |
| 100CLZ-6B | 75 | 62 | 2900 | 4.5 | 5.5 | 26.4 | 30 | 48 |
| 100CLZ-18.5 | 100 | 20 | 2900 | 4.8 | 5.2 | 9.1 | 11 | 60 |
| 100CLZ-18.5A | 95 | 18 | 2900 | 4.8 | 5.2 | 8.03 | 11 | 58 |
| 100CLZ-13 | 100 | 32 | 2900 | 4.8 | 5.2 | 13.8 | 18.5 | 63 |
| 100CLZ-13A | 95 | 28 | 2900 | 4.8 | 5.2 | 11.7 | 15 | 62 |
| 100CLZ-9 | 100 | 50 | 2900 | 4.5 | 5.5 | 22 | 30 | 62 |
| 100CLZ-9A | 95 | 46 | 2900 | 4.5 | 5.5 | 19.5 | 22 | 61 |
| 100CLZ-6.5 | 100 | 80 | 2900 | 4.5 | 5.5 | 39.6 | 45 | 55 |
| 100CLZ-6.5A | 95 | 75 | 2900 | 4.5 | 5.5 | 35.9 | 45 | 54 |
| 100CLZ-5 | 100 | 120 | 2900 | 4.5 | 5.5 | 62.8 | 75 | 52 |
| 100CLZ-5A | 95 | 110 | 2900 | 4.5 | 5.5 | 55.8 | 75 | 51 |
| 125CLZ-5 | 120 | 120 | 2900 | 5 | 5 | 76.8 | 90 | 51 |
| 125CLZ-9 | 200 | 80 | 2900 | 5.2 | 4.8 | 75.1 | 90 | 58 |
| 125CLZ-23.5 | 160 | 20 | 2900 | 5.2 | 4.8 | 13.4 | 18.5 | 65 |
| 125CLZ-23.5A | 150 | 18 | 2900 | 5.2 | 4.8 | 11.5 | 15 | 64 |
| 125CLZ-16.5 | 160 | 32 | 2900 | 5.2 | 4.8 | 22.1 | 30 | 63 |
| 125CLZ-16.5A | 150 | 28 | 2900 | 5.2 | 4.8 | 18.4 | 22 | 62 |
| 125CLZ-12 | 160 | 50 | 2900 | 5.2 | 4.8 | 35.1 | 45 | 62 |
| 125CLZ-12A | 150 | 46 | 2900 | 5.2 | 4.8 | 30.8 | 37 | 61 |
| 125CLZ-8 | 160 | 80 | 2900 | 5.2 | 4.8 | 60.1 | 75 | 58 |
| 125CLZ-8A | 150 | 75 | 2900 | 5.2 | 4.8 | 52.8 | 75 | 58 |
| 125CLZ-8B | 150 | 68 | 2900 | 5.2 | 4.8 | 48.7 | 55 | 57 |
| 125CLZ-6 | 160 | 120 | 2900 | 5.2 | 4.8 | 95.1 | 110 | 55 |
| 125CLZ-6A | 150 | 110 | 2900 | 5.2 | 4.8 | 83.2 | 110 | 54 |
| 150CLZ-21 | 250 | 32 | 2900 | 6 | 4 | 33.5 | 45 | 65 |
| 150CLZ-21A | 240 | 28 | 2900 | 6 | 4 | 28.2 | 37 | 65 |
| 150CLZ-14 | 250 | 50 | 2900 | 6 | 4 | 53.2 | 75 | 64 |
| 150CLZ-14A | 240 | 46 | 2900 | 6 | 4 | 47.7 | 55 | 63 |
| 200CLZ-12 | 300 | 30 | 2900 | 5.5 | 4.5 | 40.9 | 45 | 60 |
| 200CLZ-12A | 280 | 25 | 2900 | 5.5 | 4.5 | 32.9 | 37 | 58 |
| 200CLZ-24.5 | 450 | 15 | 2900 | 6 | 4 | 34.04 | 37 | 54 |
| 200CLZ-19 | 300 | 30 | 2900 | 6 | 4 | 36.3 | 45 | 60 |
| 200CLZ-19A | 300 | 30 | 2900 | 5.5 | 4.5 | 40.8 | 55 | 60 |
| 200CLZ-20.5 | 500 | 20 | 2900 | 6 | 4 | 43.9 | 55 | 62 |
