Marine Stainless Steel Vertical Multistage Centrifugal Pump
Marine Stainless Steel Vertical Multistage Centrifugal Pump
TPY series vertical multistage centrifugal pump, all material is stainless steel. For conveying the temperature between -40c to +120c of water, soft water,swimming pool water or slightly alkaline,and other stainless steel(304 or 316L)had no significant corrosion of the liquid,widely used in liquid transport,hot and cold clean water and softened water,mineral water and distilled off circulation and pressurization. Low noise,corrosion resistance, beautiful appearance,small size,smooth opreation,easy installation,long service life.
Model Explanation
For the model TPY2-69
TPY-stainless steel vertical multi-stage centrifugal pump
2-Capacity 2m3/h
69-Head 69m
Technical parameter:
| Model range | TPY1 | TPY2 | TPY3 | TPY4 | TPY5 | TPY8 | TPY12 | TPY16 |
| Capacity(m3/h) | 1 | 2 | 3 | 4 | 5 | 8 | 12 | 16 |
| Flow limitation(m3/h) | 0.6-2.0 | 1-3.5 | 1.2-4.0 | 2.0-8.0 | 2.0-8.0 | 5.0-12.0 | 7.0-16.0 | 8.0-22.0 |
| Max pressure(bar) | 22 | 22 | 22 | 22 | 22 | 21 | 21 | 21 |
| Motor power(kw) | 0.37-1.5 | 0.37-3 | 0.37-3 | 0.55-4 | 0.37-4 | 1.1-7.5 | 1.5-11 | 2.2-15 |
| Maximum efficiency | 48 | 48 | 57 | 60 | 62 | 63 | 63 | 68 |
