Portable Gasoline Fire Pump
the Technical parameter of Portable Gasoline Fire Pump:
|
Set
|
Model
|
13A-G
|
20A-G
|
|
Name
|
Portable gosoline fire pump
|
|
Inlet/Outlet diameter
|
65mm(2.5")
|
80mm(3")
|
|
Cont. Capacity(m3/h)
|
37.2
|
37.2
|
|
Cont. Head lift(m)
|
65
|
65
|
|
Suction.Time
|
20s
|
20s
|
|
Max.Suction head(m)
|
8
|
8
|
|
Max.Capacity(m3/h)
|
45
|
51
|
|
Max.Head lift(m)
|
75
|
75
|
|
Engine
|
Engine model
|
G390
|
G620
|
|
Cylinder number
|
single
|
double
|
|
Engine type
|
4-stroke,air
cooled, gasoline engine
|
|
BorexStroke(mm)
|
88x75
|
77x66
|
|
Displacement(ml)
|
397
|
598
|
|
Rated power(kw)
|
5.7
|
15
|
|
Max.output power(HP)
|
13
|
20
|
|
Rated spee(RPM)
|
3000
|
3000
|
|
Mix.Spee(RPM)
|
<1300
|
<1300
|
|
Fuel consumption ratio(g/kw.h)
|
<390
|
<395
|
|
Fuel type
|
90#,93#,97#
|
|
Oil type
|
SAE15W-40
|
|
|
starting method
|
Electric start
|
|
Fuel tank capacity(L)
|
6
|
10
|
|
Oil capacity(L)
|
1.1
|
1.3
|
|
Pack
|
Packing size(mm)
|
810x490x550
|
850x910x690
|
|
Net weight(Kgs)
|
65
|
67
|
|
Gross weight(Kgs)
|
80
|
90
|
