KG-2T Public Address Main Unit

KG-2T Public Address Main Unit

KG-2T Public Address Main Unit Function

Remote control: Remote control broadcast can be achieved by connected remote control box.

Talkback: mutual talkback can be carried out with remote control box.

Alarm: It has interface to general alarm system, can receive the alarm signal from general alarm system.

Output: It has outputs of shout, cabin, deck and post, hereinto, cabin and post has forced full volume output function.

Protection: Output short circuit and overload protection.

Entertainment: With MP3 player, FM radio.

When shout speaker is working, other speaker will be closed forcedly,

Talkback function: Mutual talkback between remote control boxes, maximum six remote control boxes should be connected.

Product Technical Parameter

Nonlinear distortion: ≤7%

Signal to noise ratio: ≥46dB

Output power: 2x50W/2x100W/2x200W/2x300W

Receiving Frequency range: FM 87~108MHz

Sensitivity: FM≤20µV

Play frequency response: 150Hz~5KHz±2dB

Main Power: Two lines AC220V±10%

Emergency power: Two lines DC24V (-25%~+30%)

Color: Sea gray (RAL7035)

IP Class: IP20

Weight: 6.0KG

Power loss: 200W/400W/800W/1200W

KG-2T Mounting Size
