HDP-1100-1 Type Fuel injector testbed test bench

HDP-1100-1 Type Fuel injector testbed test bench

China HDP-1100-1 Type Fuel injector testbed test bench:

Output pressure: Max.1100Bar at 10Bar air input. Max 800Bar at 7Bar
Air consumption: 60.5Litres/cycle at 10Bar input. 44Litres/cycle at 7Bar
Max.flow at no pressure: Approx 1.2Litres/Min at an air input of 7Bar up
Pumping speed: Approx 60cycles/min at 7Bar up air input, and no output pressure
Displacement per cycle: 20ML3-1.22CU.IN
Tank capacity: 6L
Weight: 90KG
Dimensions: 560*950*1525mm

Packing and Delivery：

1. Standard Export Packing or Seaworthy Packing, if you have special requirement, please specify when inquiry.
2. Fast Delivery, delivery time can negotiate when order.

How to Order?

1. Please inform us the model, type or size you need.
2. Please inform us the quantity to make the best price for you.
3. Shipment Model: Air or Sea shipment.
4. Special requirement if any.
