CXH10-1 Navigation Signal Light
The scope of application
Applied to all types of ships as lamp signal identification when the formation ships night navigation
Products feature
1. It can change perspective and adjust the light intensity according to the navigation requirement.
2. The shell is made of good quality cast brass or cast aluminum.
3. Fine seal performance and can prevent from the sea water intrusion.
4.Cable outside diameter is Φ11mm
Adopt standard
Conform to RULES FOR CLASSIFICATION OF SEA-GOING STEEL SHIPS.
Installation
CXH10-1 Navigation Signal Light Specification
| Name | Wake Light |
| Type | CXH10-1 |
| Visibility | 2n.m |
| Horizontal Angle | 10° |
| Vertical Angle | 30° |
| Voltage/Power | 220V/2*25W |
| Lamp Holder | B22d |
| Material | Brass/Aluminum |
| Protection Class | IP56 |
| Weight | 9.3kg/5.3kg |
