6 Strand Polyamide Rope
China 6 Strand Polyamide Rope:
6 Strand Polyamide Rope
Structure: 6 strand
Density:1.14, sinking in water.
Melt point:215 centigrade
Elongation rate: 15% to 25%
Good abrasion resistance and good corrosion assistance.
Parameter Table:
| Diameter | Circumference | Linear Density | Breaking Strength | ||||
| mm | Inch | mm | Inch | Ktex | lb/foot | Tons | KN |
| 28 | 1-1/8 | 87.92 | 3-1/2 | 495 | 0.333 | 15.92 | 156 |
| 32 | 1-5/16 | 100.48 | 4 | 640 | 0.43 | 20.1 | 197 |
| 36 | 1-1/2 | 113.04 | 4-1/4 | 815 | 0.548 | 25.1 | 246 |
| 40 | 1-5/8 | 125.6 | 5 | 1010 | 0.679 | 30.2 | 296 |
| 44 | 1-3/4 | 138.16 | 5-1/2 | 1260 | 0.847 | 36.12 | 354 |
| 48 | 2 | 150.72 | 6 | 1450 | 0.974 | 42.35 | 415 |
| 52 | 2-1/8 | 163.28 | 6-1/2 | 1690 | 1.136 | 49.18 | 482 |
| 56 | 2-1/4 | 175.84 | 7 | 1970 | 1.324 | 56.43 | 553 |
| 60 | 2-1/2 | 188 | 7-1/2 | 2250 | 1.512 | 64.39 | 631 |
| 64 | 2-5/8 | 201 | 8 | 2570 | 1.727 | 72.65 | 712 |
| 72 | 3 | 226 | 9 | 3250 | 2.184 | 90.71 | 889 |
| 80 | 3-1/8 | 251 | 10 | 4020 | 2.702 | 110.92 | 1087 |
| 88 | 3-1/2 | 276 | 11 | 4870 | 3.273 | 132.24 | 1296 |
| 96 | 3-3/4 | 302 | 12 | 5790 | 3.891 | 166.53 | 1632 |
