360 Degree Swivel Fairlead
China 360 Degree Swivel Fairlead:
Description:
360 degree rotation swivel fairlead, anchor fairlead, deck mounted multi angle fairlead.
Drawing:
Size Chart:
| Wire Rope Dia. | Sheave Dia.(mm) | Dimension(mm) | Mass Weight | ||
| mm | A | B | C | kg | |
| 25 | 254 | 559 | 356 | 679 | 420 |
| 32 | 305 | 711 | 508 | 889 | 720 |
| 38 | 406 | 762 | 762 | 1296 | 1080 |
| 44 | 508 | 1067 | 914 | 1568 | 2260 |
| 50 | 610 | 1219 | 1067 | 1893 | 2480 |
| 64 | 762 | 1372 | 1219 | 2127 | 2900 |
