Stainless Steel TW Anchor
Stainless Steel TW Anchor Description
Material: SS316
Weight: 18kgs to 1000kgs
Surface Finish: Mirror Polished.
High Quality and Fast Delivery, please contact us for more details.
| Nominal
Weight (KG) | Size(mm) | |||||
| A | B | C | D | E | F | |
| 20 | 369 | 374 | 144 | 240 | 136 | 402 |
| 32 | 435 | 437 | 168 | 280 | 158 | 469 |
| 40 | 469 | 476 | 183 | 305 | 172 | 510 |
| 60 | 536 | 544 | 210 | 349 | 197 | 585 |
| 75 | 578 | 587 | 225 | 376 | 212 | 630 |
| 80 | 600 | 610 | 225 | 400 | 222 | 685 |
| 90 | 615 | 624 | 240 | 400 | 226 | 670 |
| 105 | 648 | 658 | 252 | 422 | 240 | 710 |
| 125 | 686 | 694 | 267 | 447 | 254 | 750 |
| 135 | 705 | 716 | 274 | 459 | 261 | 773 |
| 145 | 720 | 730 | 280 | 470 | 266 | 788 |
| 160 | 746 | 758 | 290 | 486 | 276 | 818 |
| 180 | 776 | 787 | 301 | 505 | 287 | 850 |
| 225 | 836 | 848 | 325 | 544 | 309 | 915 |
| 270 | 888 | 902 | 342 | 573 | 326 | 965 |
| 300 | 920 | 933 | 357 | 598 | 340 | 1008 |
| 360 | 978 | 993 | 380 | 637 | 362 | 1072 |
| 400 | 996 | 1010 | 386 | 648 | 374 | 1090 |
| 450 | 1038 | 1053 | 403 | 675 | 390 | 1137 |
| 490 | 1086 | 1103 | 422 | 707 | 402 | 1190 |
| 565 | 1136 | 1153 | 425 | 740 | 420 | 1245 |
| 582 | 1160 | 1180 | 450 | 755 | 428 | 1270 |
| 675 | 1205 | 1224 | 468 | 785 | 446 | 1322 |
| 765 | 1257 | 1276 | 488 | 818 | 465 | 1378 |
| 855 | 1286 | 1306 | 500 | 841 | 480 | 1411 |
| 1000 | 1360 | 1380 | 528 | 885 | 503 | 1480 |
