Air Breathing Apparatus Inflator Pump
Category:
Self Contained Breathing Apparatus
Certificate:
ABS,LR,BV,DNVGL,NK,KR,IRS,RMRS,CCS
FOB Price:
Get Latest Price Now
Warranty:
12 Months unless specified otherwise
Place of Origin:
China
Request a Quote Print this page
We can supply according to your requirement.
Air Breathing Apparatus Inflator Pump:
China Air Breathing Apparatus Inflator Pump:

Air Breathing Apparatus Inflator Pump

With automatic shutdown feature, enabling charging process unattended, to provide you with greater security.

Feature:

MCH6 series of breathing air compressor is the industry's smallest,Lightest portable breathing air compressors, the petrol-driven engine only 37KG, you can easily put it into the trunk of a car, maneuvering to use site for fire, diving, shooting, emergency rescue, chemical, oil and other leading domain, with easy to move, easy to operate, and the compression manufacturing digh-pressure air line with EU EN 12021 standards.

Structure:

Optional gasoline engine, three-phase, single phase electric drive motor, V belt drive four-cylinder

four-pole high-pressure compressor
Stainless steel interstage cooler
installed on the compressor 00bar pressure gauge
1.2 m high pressure pneumatic hose, pneumatic fittings needed to configure your Stainless steel fan cover
two oil-water separator, two drain valve (optional automatic sewage)
carbon molecular sieve filtration system
reaches the set pressure is automatically shut down to prevent frequent start valve jump to protect the personal safety.

MCH6 type Mobile portable breathing air inflator
compressors
Model MCH6/et MCH6/em MCH6/sh
Working pressure Firefighting : 300 Bar 30Mpa 4300 Psi Diving
:225Bar 22.5 Mpa 3300 Psi
Charging rate 100L/min
6m3/H 3.5CFM
80L/min
4.8m3/H 2.8CFM
100L/min
6m3/H
Filling time cylinder 6.8L
0-300 bar/ 20.4 min
6.8L
0-300 bar / 25.5 min
6.8L
0-300 bar / 20.4 min
12L 0-200 bar/ 24 min 12L 0-200 bar /
30 min
12L 0-200 bar /
24 min
Driven by Three-phase electric motor Single-phase electric motor Honda petrol engine
power 3
Kw
2.2
Kw
3.6
Kw / 5.5Hp
Noise pressure 83
dB
81.7
dB
87.5
dB
Dry weight 39
Kg / 85 lbs
39
.5Kg / 87 lbs
37
.5Kg / 81.5 lbs
dimensions Height
35cm
Height
35cm
Height
35cm
width 65cm width65cm Width 78cm
depth 39cm depth 39cm depth 32cm
Breathing air standards EN 12021 DIN 3188 CAG E
