2-4 inch Gasoline self-priming Water Pump
Category:
Diesel And Gasoline Water Pump
Certificate:
ABS,LR,BV,DNVGL,NK,KR,IRS,RMRS,CCS
FOB Price:
Get Latest Price Now
Warranty:
12 Months unless specified otherwise
Place of Origin:
China
Request a Quote Print this page
We can supply according to your requirement.
2-4 inch Gasoline self-priming Water Pump:
2-4 inch Gasoline self-priming Water Pump
Technical parameter:

Set Model 50KB-2G 80KB-3G 100KB-4Ga 100KB-4Gb
Name Gasoline self-priming water pump
Inlet/Outlet diameter 50mm(2") 80mm(3") 100mm(4") 100mm(4")
Cont. Capacity(m3/h) 33 60 80 80
Cont. Head lift(m) 30 30 25 25
Max.Suction head(m) 8 8 8 8
Engine Engine model 170F 170F 170F 177F
Engine type Single cylinder,4-stroke,air cooled gasoline engine
Displacement(CC) 208 208 208 270
Max.output power(HP) 7.5 7.5 7.5 10
Rated spee(RPM) 3600 3600 3600 3600
Fuel consumption ratio(g/kw.h) <390 <390 <390 <390
starting method Recoil start
Fuel tank capacity(L) 3.6 3.6 6 6
Options Electric starter N/A N/A Available Available
Oil annunciator N/A N/A Available Available
Pack Packing size(mm) 480x390x400 520x395x450 615x445x540 615x445x540
Net weight(Kgs) 24 27 45 47
Gross weight(Kgs) 26 29 47 49
20FT Qty 365 335 192 192
